R134a Series Screw Chiller 340kW - 2100kW Industrial-Grade Cooling Solution
The R134a Series Screw Chiller represents decades of expertise in large-capacity cooling solutions. Featuring industrial-grade semi-hermetic twin-screw compressors and high-efficiency flooded shell-and-tube heat exchangers, this series delivers reliable performance for medium to large commercial, industrial, and process cooling applications.
With cooling capacities ranging from 340kW to 2100kW, the R134a series offers versatile configurations including heat recovery units, ice storage systems, high-temperature water units, and large temperature differential models to meet diverse customer requirements.
The advanced oil management system with triple-stage oil separation ensures stable operation under all load conditions, while the precision capacity control system enables stepless modulation from 25% to 100% for optimal energy efficiency.
Features & Benefits
- Industrial-Grade Screw Compressor - Semi-hermetic design reduces refrigerant leakage; 5-tooth/6-tooth asymmetric rotor profile with micron-level precision; Swedish SKF bearings ensure 50,000+ hours MTBF.
- High-Efficiency Flooded Evaporator - Optimized refrigerant distribution with enhanced temperature field; liquid separator prevents compressor suction with liquid, improving reliability.
- Advanced Condenser Design - Twisted-fin tube technology increases heat transfer coefficient; dual water circuit design with straight-through cleaning capability.
- Triple-Stage Oil Separation System - In-compressor + condenser + dual ensures minimal oil carryover and reliable lubrication.
- Stepless Capacity Control - 25%-100% stepless modulation precisely matches cooling output to load; advanced electronic expansion valve ensures rapid response.
- Eco-Friendly R134a Refrigerant - Zero ozone depletion potential; optional R513A for even lower global warming potential; high thermal efficiency.
- Low Noise Operation - Built-in compressor muffler; vibration-damping mountings reduce mechanical noise transmission.
- Intelligent Control System - 7-inch touch screen with RS485/Modbus interface; 20+ protection functions; remote monitoring capability via iBUILDING platform.
Applications
- Commercial Buildings - Large office complexes, shopping malls, and convention centers
- Sports Facilities - Stadiums, sports halls, and swimming pools requiring large-capacity cooling
- Industrial Process Cooling - Manufacturing, pharmaceutical, and food processing facilities
- Data Centers - Mission-critical cooling for IT infrastructure
- Telecommunications - Base station and network equipment cooling
Certifications & Standards
AHRI Certified - Air-Conditioning, Heating, and Refrigeration Institute performance certification
GB/T 18430.1 - Meets China's national standard for water chilling packages
ISO 9001 - Quality management system certification
ISO 14001 - Environmental management system certification
CE Marking - European safety, health, and environmental compliance
Technical Specifications
| Parameter |
Specification |
| Cooling Capacity |
340kW - 2100kW |
| COP (Full Load) |
5.50 - 5.85 |
| IPLV |
7.20 - 8.50 |
| Refrigerant |
R134a (Optional R513A) |
| Evaporator |
Flooded Shell-and-Tube |
| Condenser |
Shell-and-Tube with Subcooler |
| Chilled Water Inlet |
12°C |
| Chilled Water Outlet |
7°C |
| Cooling Water Inlet |
30°C - 32°C |
| Capacity Control |
25%-100% Stepless |
| Compressor |
Semi-Hermetic Twin-Screw |
| Power Supply |
380V/3Ph/50Hz |
| Noise Level |
75-88 dB(A) |
| Water Side Pressure |
1.0 MPa (Higher on request) |
